Maximize your hauling capacity with our side wall trailer. Designed for a 40,000 kg payload, this trailer is the perfect solution for transporting bulk cargo, containers, and other general goods with added security.
Side Wall Trailer Specifications
Side Wall Trailer Dimension (mm): 12410*2480*2700
Payload: 40,000 KGS
Tare weight: 8300 kg
The thickness of the buffer: 5 mm
Axle: BPW brand 13T
Suspension: germany type spring suspension with 12 pcs of leafs( 100mm* 12mm)
Type of landing leg and capacity: JOST TYPE 19″
Kingpin: 3.5″ BOLT-IN
Tires: Triangle brand 315/80R22.5
Rim: 9.00*22.5
Container locks: 12pcs
Robust and Durable, Achieve Exceptional Transport
Start your project today and get a high-performance semi-trailer solution tailored specifically to your unique needs.
The Versatility of a Side Wall Trailer
When you need a trailer that can handle a variety of cargo types, our side wall trailer is the answer. It’s designed to carry everything from bulk cargo to containers, making it an invaluable asset for logistics and transportation companies. The side walls provide an added layer of security, preventing bulk materials from shifting or spilling during transit. You can also transport containers, including a single 40ft, a single 20ft, or two 20ft containers.
Engineered for Heavy-Duty Performance
We build our trailers to last. This model features a robust 3-axle design, with each axle rated at 13 tons, ensuring it can handle the most demanding loads. It features a reliable Germany-type spring suspension with 12 pieces of leaf springs, engineered to provide a stable and smooth ride, which is crucial for protecting your cargo. The trailer is equipped with 13 sets of Triangle brand 315/80R22.5 tires and 9.00×22.5 rims, offering excellent traction and long-term durability on any road surface.
Key Features for Efficient and Secure Operations
Our side wall semi trailer is designed for a seamless workflow. The body structure includes a 5 mm buffer thickness. With a payload of 40,000 kg and a low tare weight of 8,300 kg, it is designed for maximum efficiency. The Jost type 19-inch landing gear and a 3.5-inch bolt-in kingpin from Jost provide dependable support. Additionally, the trailer includes 12 container locks, allowing you to securely fasten various container sizes.
Robust and Durable, Achieve Exceptional Transport
Start your project today and get a high-performance semi-trailer solution tailored specifically to your unique needs.
Ready to enhance your fleet’s capability? Our side wall trailer is a proven solution for businesses that demand strength and versatility. Contact us today to learn more and get a detailed quote.
Video of henred type sidewall trailer
Robust and Durable, Achieve Exceptional Transport
Start your project today and get a high-performance semi-trailer solution tailored specifically to your unique needs.
1. What is a drop-side trailer, and what makes it different from a flatbed trailer?
A drop side trailer, also known as a side wall trailer or sideboard semi-trailer, is a type of semi-trailer characterized by its removable or collapsible side panels. The primary difference from a standard flatbed is its enhanced versatility. While a flatbed trailer is only suitable for carrying large, single items that can be strapped down, a drop-side trailer can easily be converted. With the side walls and tailgate in place, it can securely transport bulk cargo like bags of cement, grain, or sand. By dropping or removing the side walls, it transforms into a flatbed trailer, allowing for the easy loading and transport of oversized goods and equipment from the side. This versatility makes the drop side semi-trailer a highly adaptable asset for a wide range of industries.
2. What types of cargo are best suited for a drop-side trailer?
The design of a drop-side trailer makes it ideal for a diverse range of cargo types, especially those that benefit from containment during transport. It is best suited for:
Bulk Cargo: Items like sacks of grain, fertilizer, or cement, where the side walls prevent the load from shifting or falling off.
Construction Materials: Pallets of bricks, stones, steel bars, or bagged materials that need to be contained but also require easy access for loading and unloading with a forklift from the side.
General Freight: Assorted goods, boxes, and smaller equipment that are difficult to secure on a flatbed alone.
Agricultural Goods: Bales of hay or other farm produce can be stacked efficiently and contained by the side walls.
The drop side semi-trailer’s ability to transition between a contained and an open platform makes it a cost-effective solution for fleets that haul various types of goods.
3. What key features should I look for to ensure a drop-side trailer is durable and safe?
To ensure your drop-side trailer is durable and safe for the long term, you should pay close attention to its construction and components.
Frame Material: Look for a robust main frame built from high-tensile steel, which provides superior strength and resistance to bending under heavy and uneven loads.
Side Wall Construction: The side panels should be made of durable steel with strong, reliable locking mechanisms that prevent accidental release during transit. The taller the side walls, the more bulk cargo you can contain.
Axles and Suspension: A high-quality suspension system (e.g., a multi-leaf spring system) and reliable axles are crucial for handling heavy payloads and providing a stable ride.
Braking System: A modern braking system with ABS (Anti-lock Braking System) is essential for safety, providing superior control and preventing skidding in emergency situations.
These features ensure that the side wall trailer can withstand daily heavy use and provide a secure platform for your cargo.
4. Can a drop-side trailer be customized?
Yes, Drop Side Trailers are one of the most customizable types of semi-trailers. While standard models are available, they can often be tailored to meet specific operational needs. Common customization options include:
Side Wall Height: The height of the side walls can be adjusted to accommodate different types of bulk cargo.
Axle Configuration: You can choose the number of axles (e.g., 2-axle, 3-axle, 4-axle) based on your regional weight regulations and payload requirements.
Suspension Type: While mechanical spring suspension is common, you can opt for an air suspension system for a smoother ride, which is better for delicate cargo.
Material and Finish: The type of steel and the paint/coating can be customized for specific environmental conditions to enhance corrosion resistance and longevity.
application scenarios
Dropside trailers are highly adaptable, making them invaluable across numerous industries where flexible loading and containment are crucial.
Construction & Building Materials: Transporting palletized bricks, bagged cement, lumber, scaffolding, tiles, and various aggregates (like sand or gravel, when contained within the sides). Their side access is ideal for delivering materials directly to tight construction sites.
Agricultural & Farming: Hauling produce (fruits, vegetables), bagged seeds, fertilizers, animal feed, and other farm supplies. The dropsides simplify manual loading and unloading in fields or farmyards.
General Cargo & Palletized Goods: Ideal for everyday freight that needs weather protection (via a tarp) but benefits from multi-directional loading, such as general merchandise, industrial parts, or packaged goods.
Waste & Recycling (Non-Compacted): Transporting certain types of non-compacted waste, scrap materials, or recyclable goods to collection or processing centers.
